Bolt 6 Series
Bolt 6 Series
6GHz
Zero-Delay
Wireless Video
6GHz
Zero-Delay
Wireless Video
True zero-delay video with
reduced signal congestion.
True zero-delay video with
reduced signal congestion.
Maximum range
Maximum range
Added 6GHz channels.
Up to 5000ft of range.
Added 6GHz channels.
Up to 5000ft of range.
Pristine Image
Pristine Image
Enhanced zero-delay 10-
bit 4:2:2 wireless
video.
Enhanced zero-delay 10-
bit 4:2:2 wireless
video.
Secure. Safe. Legal.
Secure. Safe. Legal.
Enhanced DFS and
AES-256 encryption.
Fully FCC/CE
compliant.
Enhanced DFS and
AES-256 encryption.
Fully FCC/CE
compliant.
Unprecedented
Control
Unprecedented
Control
Manage signal quality,
LUT output, and more in
the Bolt App.
Manage signal quality,
LUT output, and more in
the Bolt App.
Extended Workflow
Extended Workflow
Unlock camera control.
Pass timecode, filename,
and metadata.
Unlock camera control.
Pass timecode, filename,
and metadata.
CROSS COMPATIBLE
CROSS COMPATIBLE
Connects to all Bolt 6 and Bolt 4K Devices.
Connects to all Bolt 6 and Bolt 4K Devices.
Explore Bolt 6
Choose the Bolt and antenna option that
fits your workflow.
More Channels, Less Interference
More Channels, Less Interference
A Breath of
Fresh Airwaves
A Breath of
Fresh Airwaves
Bolt 6 adds 12 new 6GHz channels to the standard 5GHz options.
When searching for the perfect channel with no
interference, this
doubles the total number of frequencies you can choose from.
The more frequencies you have, the
better your signal.
Bolt 6 adds 12 new 6GHz channels to the standard 5GHz options.
When searching for the perfect channel with no
interference, this
doubles the total number of frequencies you can choose from.
The more frequencies you have, the
better your signal.
Bolt Manager App
Bolt Manager App
Channel Section Just Got Easier
Channel Section Just Got Easier
Go full automatic or become a
power user by defining your own.
Go full automatic or become a
power user by defining your own.
Broadcast Mode
Pair your transmitter with unlimited
receivers
in Broadcast Mode.
MAX Model Required.
Broadcast Mode
Pair your transmitter with unlimited
receivers
in Broadcast Mode.
MAX Model Required.
Broadcast Mode
Pair your transmitter with unlimited
receivers
in Broadcast Mode.
MAX Model Required.
Broadcast Mode
Pair your transmitter with unlimited
receivers
in Broadcast Mode.
MAX Model Required.
Spectrum Analyzer
Use the software spectrum analyzer to
find
the best frequency in your area.
Spectrum Analyzer
Use the software spectrum analyzer to
find
the best frequency in your area.
Spectrum Analyzer
Use the software spectrum analyzer to
find
the best frequency in your area.
Spectrum Analyzer
Use the software spectrum analyzer to
find
the best frequency in your area.
Fixed Frequencies
Override Auto Channel Selection to select the
best frequency in challenging RF environments.
Fixed Frequencies
Override Auto Channel Selection to select the
best frequency in challenging RF environments.
Fixed Frequencies
Override Auto Channel Selection to select the
best frequency in challenging RF environments.
Fixed Frequencies
Override Auto Channel Selection to select the
best frequency in challenging RF environments.
Bandwidth
Choose 20MHz or 40MHz sub-channels
to double your bandwidth.
Bandwidth
Choose 20MHz or 40MHz sub-channels
to double your bandwidth.
Bandwidth
Choose 20MHz or 40MHz sub-channels
to double your bandwidth.
Bandwidth
Choose 20MHz or 40MHz sub-channels
to double your bandwidth.
Pair with any Bolt 4K or Bolt 6
Pair with any Bolt 4K or Bolt 6
4K HDR Wireless Video with
Unrivaled Compatibility
4K HDR Wireless Video with
Unrivaled Compatibility
Customize Your Build
Customize Your Build
Antennas For
Every
Production
Environment
Antennas For
Every
Production
Environment
Bolt’s ecosystem offers different calibrated antenna
options for diversifying your RF signal,
helping you
maintain the strongest image quality possible, while
also giving you the
flexibility to build solutions that
work best for your setup.
Bolt’s ecosystem offers different calibrated antenna
options for diversifying your RF signal,
helping you
maintain the strongest image quality possible, while
also giving you the
flexibility to build solutions that
work best for your setup.
Vertically
Polarized Antennas
Vertically
Polarized Antennas
The longest range and most
affordable option.
The longest range and most
affordable option.
- External Mounting
- Omnidirectional
- Use by themselves or with other antennas
- Ranges up to 5000ft
Horizontally
Polarized Antennas
Horizontally
Polarized Antennas
Use with V Antennas to
increase signal robustness.
Use with V Antennas to
increase signal robustness.
- External Mounting
- Omnidirectional
- Use in combination with V antennas
- Ranges up to 3000ft
Directional
Array Antenna
Directional
Array Antenna
Aim your RF signal to avoid
physical obstructions.
Aim your RF signal to avoid
physical obstructions.
- External Mounting
- Directional: Point Array toward TX
- Configurable with V or H Antennas
- Ranges up to 5000ft
Internal Antennas
Internal Antennas
The Bolt 6 LT and Monitor Module models
feature
permanent built-in internal antennas
that are 75%
shorter than external antenna
models, helping you
streamline your camera
rig and/or director’s monitor
and safeguard
against damage and misalignment.
The Bolt 6 LT and Monitor Module models
feature
permanent built-in internal antennas
that are 75%
shorter than external antenna
models, helping you
streamline your camera
rig and/or director’s monitor
and safeguard
against damage and misalignment.
- Built into specific Bolt 6 Models
- Omnidirectional, 360 degree
signal coverage - Use with any Bolt 4K or Bolt 6 device,
internal or external - Range of 750ft
Bolt 6
Bolt 6
Premium Features and Integrations
Premium Features and Integrations
Premium
Encryption
Premium
Encryption
RSA-1024 key pairing and AES-256 encryption blocks unauthorized
access to your wireless video feed.
RSA-1024 key pairing and AES-256 encryption blocks unauthorized
access to your wireless video feed.
Government Certified
Government Certified
All Bolts are FCC and CE certified
to be fully compliant with safety
regulations in the US, Europe,
Japan, and many other countries.
All Bolts are FCC and CE certified
to be fully compliant with safety
regulations in the US, Europe,
Japan, and many other countries.
Health Check
Health Check
A suite of powerful tools to help you
troubleshoot and test
your
hardware and cabling including:
Antenna Self-Test,
SDI
Cable
Quality Check, and Test Patterns.
A suite of powerful tools to help you
troubleshoot and test
your
hardware and cabling including:
Antenna Self-Test,
SDI
Cable
Quality Check, and Test Patterns.
Use Your Metadata
Use Your Metadata
Bolt 6 passes all crucial SDI
metadata from ARRI, RED®,
and
select Sony and Canon cameras to
your monitors,
Livegrade,
and/or
cloud platforms like Teradek TV.
Bolt 6 passes all crucial SDI
metadata from ARRI, RED®,
and
select Sony and Canon cameras to
your monitors,
Livegrade,
and/or
cloud platforms like Teradek TV.
Unlock
Wireless
Camera Control
Unlock Wireless
Camera Control
Bolt 6 integrates
seamlessly with
the SmallHD ecosystem
to let you
remotely control ARRI, RED®, or
Sony
cameras.
Bolt 6 integrates seamlessly with
the SmallHD ecosystem
to let you
remotely control ARRI, RED®, or
Sony
cameras.
Complete HDR
Imaging Pipeline
Complete HDR
Imaging Pipeline
Bolt 6 gives
you expansive HDR
capabilities with 10-bit
4:2:2 and
Rec. 709, Rec. 2100, or LOG
throughput.
Bolt 6 gives you expansive HDR
capabilities with 10-bit
4:2:2 and
Rec. 709, Rec. 2100, or LOG
throughput.
the Field
Testimonials from the Field
Testimonials from the Field
“6GHz in Bolt 6 has been a life saver. It’s
come through in some really challenging RF
environments where the 2.4 and
5.8GHz
bands have been completely congested.”
“6GHz in Bolt 6 has been a life saver. It’s
come through in some really challenging RF
environments where the 2.4 and
5.8GHz
bands have been completely congested.”
Dan Ming | 1st AC, Local 600
Dan Ming | 1st AC, Local 600
Top Gun: Maverick, Formula 1
Top Gun: Maverick, Formula 1
“Today’s onset RF environment is
increasingly congested. Bolt 6 makes
wireless video stress free, putting more time
on screen."
“Today’s onset RF environment is
increasingly congested. Bolt 6 makes
wireless video stress free, putting more time
on screen."
Calvin Reibman | DIT, Local 600
Calvin Reibman | DIT, Local 600
Ferrari, Devotion
Ferrari, Devotion
“We just switched to Bolt 6s on SEAL team. WOWSER! What a better image.”
“We just switched to Bolt 6s on SEAL team. WOWSER! What a better image.”
Raul Riveros | DIT, Local 600
Raul Riveros | DIT, Local 600
SEAL Team, Sonic the Hedgehog 2
SEAL Team, Sonic the Hedgehog 2
"My Bolt 6 systems have worked flawlessly
in huge stadiums with tens of thousands of
people and challenging wireless
environments. Getting 4K ultra low latency
high fidelity images live on stage has truly
elevated our imaging game.”
"My Bolt 6 systems have worked flawlessly
in huge stadiums with tens of thousands of
people and challenging wireless
environments. Getting 4K ultra low latency
high fidelity images live on stage has truly
elevated our imaging game.”
Lonny Danler | DIT, Local 600
Lonny Danler | DIT, Local 600
Ford v Ferrari, Jumanji: The Next Level
Ford v Ferrari, Jumanji: The Next Level
Compare
Bolt 6 Models
Available Ranges
Available Ranges
750 ft / 1500 ft / 5000+ ft
750 ft / 1500 ft / 5000+ ft
750 ft / 1500 ft
Maximum SDI Resolution
Maximum SDI Resolution
4096 x 2160p60
1920 x1080p60
Maximum HDMI Resolution
Maximum HDMI Resolution
4096 x 2160p60
3840 x 2160p30
3840 x 2160p30
Maximum Color
Maximum Color
SDI: 4:2:2 YCbCr
10-bit
HDMI: 4:4:4 RGB
8-bit
SDI: 4:2:2 YCbCr
10-bit
HDMI: 4:4:4 RGB
8-bit
HDMI: 4:4:4 RGB
8-bit
Zero-Delay
Zero-Delay
6GHz Support
6GHz Support
Receiver Connectivity
Receiver Connectivity
6/Unlimited*
6/Unlimited*
6
SmallHD Wireless Camera
Control Port
SmallHD Wireless Camera
Control Port
Built-in 5pin USB
Requires Adaptor
Compatible with Bolt 4K
Compatible with Bolt 4K
Internal Antennas
Internal Antennas
750 Transmitter / 750 Receiver
750 Receiver
* Unlimited receiver connectivity
requires
the Bolt 6 XT/LT MAX model
Shop Bolt 6
Choose the option that is right for you
plan with
Talk to a
Product Specialist
Talk to a
Product Specialist
Contact us for more information on the Bolt 6 Series
Contact us for more information on the Bolt 6 Series
